4KSignal Video Switcher HDS9325 Record/Stream/Luma/Chroma

HDMI SDI DVI 高清切换台

It is a dedicated video switcher for broadcast & TV, The DeviceWell HD Video Switcher HDS9325 adopts a portable integrated design and comes with an 11.6-inch HD monitor screen, which can directly multiview output. Standard size: 285mm* 190mm*42.6mm,  The equipment integrates common components of switcher such as multiview processor, special effect generator, audio processor, control keyboard and so on.

The video signal interface supports 4-CH HD/DVI/XVI+1-CH DP, total 5-CH video input and 2-CH HD/DVI/XVI output.

The audio signal interface supports 2-CH MIC input, 1-CH LINE input, and 1-CH Line output.

Support DCB control system and tally output.

It adopts high-strength aluminum alloy shell, which is easy to carry. It can be applied to broadcast and TV station studios and the needs of switching video effects on location. For professional users, the control keyboard can be expanded through the DCB interface.




  • Broadcast & TV standard Tally interface

  • Support USB3.0 interface UVC output

  • 1 group of KEY, support Luma key, chroma key,key image and superimposed character function

  • Support RJ45 remote control

  • Support DCB control

  • 2xMIC inputs

  • 1xLINE IN input

  • 1xLINE OUT output

  • 4xHD/DVI/XVI+1xDP input

  • MULTIVIEW output:1xHD/DVI/XVI

  • PGM output:2xHD/DVI/XVI



Support 4K Signal Input 4xDVI+1xDP Video Switcher- HDS9125

HDMI SDI DVI 高清切换台

It is a dedicated video switcher for broadcast & TV, The DeviceWell HD Video Switcher HDS9125 adopts a portable integrated design and comes with an 11.6-inch HD monitor screen, which can directly multiview output. Standard size: 285mm* 190mm*42.6mm,  The equipment integrates common components of switcher such as multiview processor, special effect generator, audio processor, control keyboard and so on.

The video signal interface supports 4-CH DVI+1-CH DP, total 5-CH video input and 2-CH DVI output.

The audio signal interface supports 2-CH MIC input, 1-CH LINE input, and 1-CH Line output.

Support DCB control system and tally output.

It adopts high-strength aluminum alloy shell, which is easy to carry. It can be applied to broadcast and TV station studios and the needs of switching video effects on location. For professional users, the control keyboard can be expanded through the DCB interface.




  • Broadcast & TV standard Tally interface

  • Support USB3.0 interface UVC output

  • Support RJ45 remote control

  • Support DCB control

  • 2xMIC inputs

  • 1xLINE IN input

  • 1xLINE OUT output

  • 4xDVI+1xDP input

  • MULTIVIEW output:1xDVI

  • PGM output:2xDVI



DeviceWell 4HDMI+1DP +Record/Stream USB3.0 Switchers HDS9335

HDMI SDI DVI 高清切换台

DeviceWell  4HDMI+1DP Switchers -HDS9335, supports 4 HDMI + 1 DP signal input, a total of 5 video signals. The external preview signal can be output synchronously. Switcher supports HDMI embedded audio + external analog audio. After mixing, it can be embedded in the output HDMI signal or output from the analog port. The resolution of all input signals is automatically adapted, and the output signal resolution can be selected as required, which is quite flexible. For broadcast and television, program production, on-site interview and speech production, outdoor sports events, school courseware production and other video switching needs, the functions of Switcher can fully meet.


◆ Portable integrated design

◆ Comes with 11.6-inch/15.6-inch LCD display

◆ Aluminum alloy body, high

strength and light weight

◆ Integrated control keyboard

audio fader and video fader

◆ Support up to 4 HDMI+1 DP inputs

◆ 2 MIC inputs

◆ 3.5mm analog audio input and output

◆ 1 channel 3.5 headphone monitor

◆ Support network RTMP streaming

◆1 group of KEY, support Luma key, chroma key,

 key image and superimposed character function





DeviceWell 4xSDI and 2x HDMI Switcher HDS9106 New Version

HDMI SDI DVI 高清切换台

DeviceWell HD Video Switcher HDS9106 adopts portable integrated design, Clamshell metal casing, standard size: 384*250*76.5 mm, which can be used for video special effects switching in small outdoor scenes. The device integrates common components such as multiview processor, special effects generator, audio processor, and control keyboard.

The HDS9106 supports 4 channels of broadcast SDI and 2 channels of HDMI for a total of six video signals. The external preview signal can be output synchronously. The HDS9106 supports SDI embedded audio + external analog audio. After mixing, it can be embedded in the output SDI signal or output from the analog port. The resolution of all input signals is automatically adapted, and the output signal resolution can be selected as required, which is quite flexible. For the video switching needs of broadcast TV, outdoor sports events, school courseware production, etc., the functions of HDS9106 can be fully satisfied.


◆ Supports up to 4 SDI and 2 HDMI inputs
◆ 3.5mm analog audio input and output
◆ 1-channel lotus seat audio input and output
◆ Support PIP/POPscreen windowing function
◆ Audio support follow and mix assignment mode
◆ PGM output: 2-CH SDI and 1-CH HDMI
◆ Multiview output: 1 CH HDMI and 1 CH SDI
◆ Support special effects switching such as MIX / FADE/WIPE
◆ Support CUT hard support for AUTO effect switching
◆ Transition rate adjustable
◆ Support Tally / network remote control
◆ Support 1 channel SDI output custom PGM/PVW
◆ Built-in chassis temperature detection and fan intelligentcontrol system
◆ Support software online upgrade





4 SDI Chroma Record Dual Stream Switcher--DeviceWell HDS6305

HDMI SDI DVI 高清切换台

The HDS6305, a dedicated switcher for Broadcast & TV / studio, adopts a portable integrated design, metal shell, small size and light weight, which can be applied to the video special effect switching requirements of small scenes. The device integrates multiview processor, special effect generator, audio processor, control keyboard and other common switcher components.

HDS6305 conforms to the SMPTE standard and supports 4-CH SDI signal input, a total of 4-CH video signals. Simultaneous output of multiview and PGM signals. HDS6305 supports HDMI embedded audio + external analog audio. After mixed processing, it can be embedded into the output HDMI signal or output from the analog port. The resolution of all input signals is automatically adapted, and the resolution of output signals can be selected according to requirements, which is quite flexible. For broadcast and television, program production, on-site production of interviews and speeches, outdoor sports events, and other video switching requirements, the functions of HDS6305 can fully meet the needs.






◆ Portable integrated design

◆ 4-CH SDI  input

◆ TF card to record PGM screen

◆ Network RTMP streaming

◆ USB3.0 streaming

◆ DCB2 control + video expansion

◆ GPI control, support foot pedal, control handle, etc.

◆ MIC and LINE audio input

◆ Analog LINE audio output

◆ Audio follow, mix function

◆ One-key screen freeze(STILL) function

◆ PVW (multiview) and PGM (live)

◆ Special effects transition such as MIX/FADE

◆ CUT hard cut and AUTO special effect transition

◆ Support tally/network remote control

◆ Built-in chassis temperature detection and fan intelligent control system

◆ Support software online upgrade
